SENSIT Trak-It IIIa Series Combustible Gas Indicators-

Downloads: datasheet manual

SENSIT Trak-It IIIa Series Combustible Gas Indicators

These Combustible Gas Indicators are designed for extreme working conditions. They are ideal for Natural Gas Transmission Pipelines, Fire Departments, Hazmat Responders, and Industrial Maintenance. They can display up to 4 gasses simultaneously, and have ATEX and UL Certifications.

SENSIT Trak-It IIIa EX Single Gas Combustible Gas Indicator, %LEL
Trak-It IIIA EX $1,204.60 USD
Was: $1,268.00
Availability:
1 to 2 Weeks
SENSIT Trak-It IIIa EX/CO 2-Gas Combustible Gas Indicator, %LEL, CO
Trak-It IIIA EX/CO $1,651.10 USD
Was: $1,738.00
Availability:
2 to 3 Weeks
SENSIT Trak-It IIIa EX/TOX 2-Gas Combustible Gas Indicator, %LEL, H2S
Trak-It IIIA EX/TOX $1,651.10 USD
Was: $1,738.00
Availability:
2 to 3 Weeks
SENSIT Trak-It IIIa EXplus 2-Gas Combustible Gas Indicator, %LEL, O2
Trak-It IIIA Explus $1,651.10 USD
Was: $1,738.00
Availability:
2 to 3 Weeks

SENSIT Trak-It IIIa Offers

Designed for confined space applications. This multi gas detector is available for areas requiring UL, CSA and IECEx/ATEX certification.

Features

  • Intrinsically Safe Design (Certified)
  • 2-Speed Internal Pump
  • Identifies Natural Gas vs Propane Gas
  • Lowest Cost, Long Life Sensors
  • LED Warning Lights
  • Large Bright Graphic Display
  • Loud Audible Alarm
  • Optional 1600 Event Auto Log
  • Exceptional Water Protection
  • Long Battery Life
  • Cost Effective As An Area Monitor
  • Infrared Downloading
  • Built-in Natural Gas and Propane Gas Calibration
  • Stainless Steel Housing
  • Meets NFPA 54 National Fuel Code for Gas Pipe Purging Requirements when equipped with TC (% volume)

Easy to get started

  1. Press Power
  2. Wait 45 Seconds for Automatic Zeroing
  3. Begin to Use
View the Quick Start Guide for More Details

Partial List of Gases Sensed

  • Butane
  • Carbon Monoxide
  • Gasoline
  • Hydrogen Sulfide
  • Methane
  • Natural Gas
  • Oxygen
  • Propane

Applications

  • Combustible Gas Leak Detection
  • Carbon Monoxide Investigations
  • Combustible Gas Measurements
  • Confined Space Monitoring
  • EPA Method 21 VOC Emissions Testing
  • Confined Space Monitoring

SENSIT Trak-It IIIa Specifications

LEL %
Resolution 0.1% up to 2%
Range 0 to 100% LEL
Accuracy ±10%
Natural Gas
Resolution 0.1%
Range 5.0-100% GAS
Accuracy ±5%
Oxygen (O2)
Resolution 0.1%
Range 0 to 25%
Accuracy ±0.2 of reading or 10% (whichever is greater)
Carbon Monoxide (CO)
Resolution 1ppm
Range 0 to 2000ppm
Accuracy ±5ppm or 5% (whichever is greater)
Hydrogen Sulfide (H2S)
Resolution 1ppm
Range 1 to 100ppm
Accuracy ±2ppm or 5% (whichever is greater)
Hydrogen Cyanide (HCN)
Resolution 1ppm
Range 0 to 30ppm
Accuracy ±2ppm or 5% (whichever is greater)
General Specifications
Dimensions 6.5 x 4 x 4.25" (16.5 x 10.2 x 10.5cm)
Weight 2.8lb (1.27kg)
Operational Temperature -4 to 104°F (-20 to 40°C)
Battery Life Alkaline: Approximately +25hrs Continuous
Click here for complete specifications on the SENSIT Trak-It IIIa Series

What's included with the SENSIT Trak-It IIIa

  • EX Combustible Gas Indicator
  • Padded Carrying Pouch
  • 4 x C Batteries
  • Neck Strap
  • External Water/Dirt Filter
  • Instruction Manual
  • Confined Space Probe

SENSIT Trak-It IIIa Videos











Click on a category to view a selection of compatible accessories with the SENSIT Trak-It IIIa Series Combustible Gas Indicators.

-
SENSIT 750-00053 Instruction Manual, TRAK-IT?IIIa 750-00053
This manual will give you further details and instruction on the gas indicator.




Review the SENSIT Technologies Trak-It IIIa Series

" data-description="These Combustible Gas Indicators are designed for extreme working conditions. They are ideal for Natural Gas Transmission Pipelines, Fire Departments, Hazmat Responders, and Industrial Maintenance. They can display up to 4 gasses simultaneously, and have ATEX and UL Certifications.">

Ask a question about SENSIT Trak-It IIIa Series Combustible Gas Indicators
